    Automatic high speed small pet bottle jars blowing molding machine 5-150ml

    Ask Lasest Price
    Brand Name : ZP
    Model Number : ZP-600
    Certification : CE;ISO9001
    Price : USD10,000-60,000
    Supply Ability : 100 SETS per month
    Delivery Time : 30 days
    • Product Details
    • Company Profile

    Automatic high speed small pet bottle jars blowing molding machine 5-150ml

    Automatic high speed small pet bottle jars blowing molding machine 5-150ml Automatic high speed small pet bottle jars blowing molding machine 5-150mlAutomatic high speed small pet bottle jars blowing molding machine 5-150mlAutomatic high speed small pet bottle jars blowing molding machine 5-150mlAutomatic high speed small pet bottle jars blowing molding machine 5-150ml

    Customized small volume bottle, patent stretch blow structure, easy to small caliber, small capacity bottles and special-shaped bottles, Applicable to the dropper, oblique mouth PET bottle, PET bottle slanting.

    ModelZP800-4ZP800-2ZP2000-4ZP2000-2ZP2000-2*ZP800-4*ZP2000-2
    MoldClamping forceKg/f32000160004800016000160003200016000
    Mold thicknessmm190180200190190190190
    Clamping strokemm260260320320320260320
    Bottom strokemm50505050505050
    Cavity pitchmm76.276.2114.3101.6114.376.2114.3
    Number of cavitiescavities4242242
    BottleMax container volumeltr0.60.62220.62
    Max neck diametermm38383838383838
    Max container diametermm686810510510568105
    Max container heightmm260260320320320260320
    Carriage Unitpcs76507250508464
    Theortical outputPcs/hr3500-40001800-22003000-40001800-2000800-20003500-4000800-2000
    ElectricPerature increasement partGroup4242254
    Levels of infrared lampsNumber of levels88101010810
    Total powerkw66348244448282
    Heating powerkw22123618222828
    AirOperating pressureKgf/cm²8888888
    Low pressure Air consumingLtr/min2000200020002000200020002000
    Blowing pressureKgf/cm²35353535353535
    High pressure Air consumingLtr/min4000200020002000200020002000
    Freezing deviceOperating pressureKgf/cm²2--42--42--42--42--42--42--4
    Temperature10--1210--1210--1210--1210--1210--1210--12
    ConsumingKcal/hr76005400114005400540076005400
    Flow rateLtr/min45306830304530
    Cooling deviceOperating pressureKgf/cm²5--65--65--65--65--65--65--6
    Temperature25252525252525
    ConsumingKcal/hr45000300004500030000300004500030000
    Flow rateLtr/min150100150100100150100
    MachineSizemm5860*23660*1840*19302250*1800*21004200*2000*22002950*1800*21002950*1800*21004100*1900*20002950*1800*2100
    WeightT4.535.5334.53
