    PET 6-cavity automatic blow molding machine factory from China Guangzhou Dongguan

    Ask Lasest Price
    Brand Name : ZP
    Model Number : ZP-600
    Certification : CE;ISO9001
    Price : USD10,000-60,000
    Supply Ability : 100 SETS per month
    Delivery Time : 30 days
    • Product Details
    • Company Profile

    PET 6-cavity automatic blow molding machine factory from China Guangzhou Dongguan

    PET 6-cavity automatic blow molding machine factory from China Guangzhou Dongguan


    Product Description

    Detailed Product Description of PET 6-cavity automatic blow molding machine:
    Double Cavity,5500-6000 bph for 700ml, could blow all kinds of shapes, different volumes of beverage bottle, candy-jars, edible oil bottle, sauces bottle, detergent bottle, cosmetic bottle, medicine bottle, health products and other shapes of containers using PET as material.
    Preform material:PET
    Output:5500-6000BPH(700ml)
    Features of PET 6-cavity automatic blow molding machine:
    1.Using hydro-pneumatic linkage mold clamping mechanism which runs stably with high speed and great clamping force.
    2.The control system adopts man-machine interface with Mitsubishi PLC which is of high sensitivity and accuracy.
    3.Using coated infrared heating lamps which enable fast and stable heating.
    4.Using centralized noise-reducing air recycling system which minimize the noise as much as possible.
    5.Using slide core in stepping unit which is easy to operate and saves energy.


    Parameters

    Parameters of PET 6-cavity automatic blow molding machine:


    ContainerMax. Container Volume700 ml
    Neck Diameter Range18-38mm
    Max. ContainerDiameter68 mm
    Max. Container Height240 mm
    Theoretical Output2000-3000 bph
    MoldingClamping stroke120 mm
    Stretching stroke240 mm
    Bottom Stoke50 mm
    Preform distance76 mm
    Preform Holder150 pcs
    Cavities6 No.

    Electrical

    System

    Max. Heating Power50 kw
    Heating Power30 kw
    Air SystemOperating Pressure8 kg/c m2
    Low Air Consumption1500 ltr/min
    Blowing Pressure35 kg/c m2
    High Air consumption2500 ltr/min
    Cooling WaterOperating Pressure5-6 kg/c m2
    Temperature8-12°C
    Flow rate60 ltr/min
    MachineSize(L×W×H)5170×2100×2000mm
    Weight5500 kg


    Auxillary machines

    Compressor High pressure

    PET 6-cavity automatic blow molding machine factory from China Guangzhou Dongguan


    Compressor low air

    PET 6-cavity automatic blow molding machine factory from China Guangzhou Dongguan


    Mold parts

    All the cavity molds(moulds) of PET 6-cavity automatic blow molding machine are manufactured by ourselves. We have our own CNC processing machine and experienced engineer, who has been making cavity molds at least 5 years. Besides the cavity molds, other hardware parts are also produced by ourselves. Thus we have strong confidence in the stability of our machine because all parts can jointed and worked as a integrated unit.

    The most frequently used material for molds are Aluminum, S136(stainless iron):


    PET 6-cavity automatic blow molding machine factory from China Guangzhou Dongguan


    PET 6-cavity automatic blow molding machine factory from China Guangzhou Dongguan

    PET 6-cavity automatic blow molding machine factory from China Guangzhou Dongguan

    PET 6-cavity automatic blow molding machine factory from China Guangzhou Dongguan

    PET 6-cavity automatic blow molding machine factory from China Guangzhou Dongguan

    PET 6-cavity automatic blow molding machine factory from China Guangzhou Dongguan
